IR Spirit FTIR (Fourier Transform Infrared Spectrophotometer) Shimadzu
IRSpirit is a compact Fourier Transform Infrared
Spectrophotometer that travels where it’s needed.
It gracefully accommodates available bench space and the sample compartment is easily accessible with the system facing forward or sidemays.
In addition, IRSpirit is equipped with the widest sample compartment in its class, to easily accommodate both Shimadzu and third-party accessories. IRSpirit also offers the highest S/N ratio (30,000:1*¹) in its class using the technology inherited from the high-end model.
Furthermore, a newly developed dedicated IR Pilot program*² offers 23 standard application programs to simplify analysis for all users.
Series Hardware :
* Interferometer :
~ Michelson interferometer (30° incident angle)
~ Equipped with Dynamic Alignment system
~ Sealed interferometer with desiccant
* Optical system : Single-beam optics
* Beam splitter : Germanium-coated KBr
* Light source :
~ High-energy ceramic
~ 3 years guaranteed
* Detector :
~ IRSpirit-T model : DLATGS detector with temperature control
~ IRSpirit-L model : LiTaO₃ detector
* Wavenumber range : 7,800 to 350 cm¯¹
* Wavenumber precision : ±0.0005cm¯¹ (@2,000cm¯¹)
* Wavenumber accuracy : ±0.1cm¯¹ (Calculate wavenumber accuracy at wavenumber correction position)
* Resolution : 0.9, 2, 4, 8, 16 cm¯¹
* S/N ration :
~ IRSpirit-T model with KBr window : 30,000:1
~ IRSpirit-T model with KRS-5 window : 23,000:1
~ IRSpirit-L model with KBr window : 13,000:1
~ IRSpirit-L model with KRS-5 window : 10,000:1 (peak-to-peak, 4 cm¯¹ resolution, in a neighborhood of 2,100 cm¯¹, 1-minute accumulation)
* Mirror speed : 2.8mm/sec
* Data sampling :
~ Semiconductor laser with temperature control
~ 6 years guaranteed
* Sample compartment :
~ Equipped with automatic accessory recognition mechanism
~ 200(W) x 140(D) x 100(H) mm
~ Center fokus
* Dimensions : 390(W) x 250 (D) x 210 (H) mm
* Required environment :
~ Operating guaranteed temperature : 10 to 35°C
~ Performance guaranteed temperature : 15 to 30°C
~ Humidity : 20-70% (KBr window model)
20-90% (KRS-5 window model) with no
condensation
* Utility ; AC 100 to 240V, 50-60 Hz
* Power consumption : 75 VA (when used), 7 VA (standby)
